中华介入放射学电子杂志 ›› 2026, Vol. 14 ›› Issue (03) : 299 -306. doi: 10.3877/cma.j.issn.2095-5782.2026.03.011

技术与方法

锁骨下静脉与颈内静脉入路完全植入式输液港在肿瘤患者中的应用及导管异位相关因素分析
吴立刚, 曾汉强, 张志成, 陈泉()
  1. 523000 广东东莞,南方医科大学第十附属医院(东莞市人民医院)介入与血管外科
  • 收稿日期:2026-02-19 出版日期:2026-08-25
  • 通信作者: 陈泉
  • 基金资助:
    2023年东莞市社会发展科技项目(20231800902712)

Comparison of Subclavian Vein and Internal Jugular Vein Approaches for Totally Implantable Access Ports in Cancer Patients and Analysis of Factors Associated with Catheter Malposition

Ligang Wu, Hanqiang Zeng, Zhicheng Zhang, Quan Chen()

  1. Interventional and Vascular Surgery, The Tenth Affiliated Hospital of Southern Medical University(Dongguan People's Hospital), Dongguan 523000, Guangdong Province, China
  • Received:2026-02-19 Published:2026-08-25
  • Corresponding author: Quan Chen
引用本文:

吴立刚, 曾汉强, 张志成, 陈泉. 锁骨下静脉与颈内静脉入路完全植入式输液港在肿瘤患者中的应用及导管异位相关因素分析[J/OL]. 中华介入放射学电子杂志, 2026, 14(03): 299-306.

Ligang Wu, Hanqiang Zeng, Zhicheng Zhang, Quan Chen. Comparison of Subclavian Vein and Internal Jugular Vein Approaches for Totally Implantable Access Ports in Cancer Patients and Analysis of Factors Associated with Catheter Malposition[J/OL]. Chinese Journal of Interventional Radiology(Electronic Edition), 2026, 14(03): 299-306.

目的

比较锁骨下静脉(subclavian vein,SCV)与颈内静脉(internal jugular vein,IJV)入路完全植入式输液港(totally implantable access port,TIAP)在肿瘤患者中的应用效果,并分析导管异位的相关因素。

方法

前瞻性纳入肿瘤病例724例,根据入路非随机分为SCV组(224例)和IJV组(500例)。比较2组盲穿成功率、手术时间、并发症及术后不适分级评分,采用Firth偏倚校正Logistic回归分析导管异位的相关因素。

结果

IJV组盲穿成功率高于SCV组(P<0.001),手术时间更长(P<0.001);SCV组导管异位率更高(P<0.001),术后不适分级评分更优(P<0.05)。Firth回归分析结果显示,IJV入路与导管异位风险降低相关(P=0.005),高龄(P=0.027)及肥胖(BMI≥28 kg/m2P=0.038)亦为导管异位相关因素。

结论

IJV入路盲穿成功率高、异位风险低;SCV入路手术时间短、术后患者报告不适程度较轻。临床应个体化选择入路。

Objective

To compare the efficacy, complications, and postoperative discomfort of totally implantable access ports (TIAP) implanted via the subclavian vein (SCV) versus the internal jugular vein (IJV) in cancer patients, and to analyze factors associated with catheter malposition.

Methods

A total of 724 cancer patients were prospectively enrolled and non-randomly assigned to the subclavian vein (SCV) group (n=224) or the internal jugular vein (IJV) group (n=500) according to the venous access approach. Blind puncture success rate, operative time, complications, and postoperative discomfort grade scores were compared between the two groups. Firth-corrected logistic regression was used to analyze factors associated with catheter malposition.

Results

The IJV group had a higher blind puncture success rate (P<0.001) but longer operative time (P<0.001) than the SCV group. The SCV group showed a higher incidence of catheter malposition (P<0.001) but better postoperative discomfort scores (P<0.05). Firth regression indicated that the IJV approach was associated with a lower risk of malposition (P=0.005); older age (P=0.027) and obesity (BMI≥28, P=0.038) were also associated factors.

Conclusion

The IJV approach offers a higher blind puncture success rate and lower malposition risk, while the SCV approach is associated with shorter operative time and milder patient-reported discomfort. Clinical selection should be individualized.

表1 患者不适分级量表
图1 右锁骨下静脉入路完全植入式输液港导管异位及调整后胸部X线片对比 患者男性,44岁升结肠腺癌并肺转移,右锁骨下静脉完全植入式输液港置入术后复查胸片提示导管异位至右侧颈内静脉(左图箭头),调整后复查胸片导管位置恢复正常(右图箭头)。
表2 并发症判定标准、诊断方式及观察周期
表3 2组患者基线资料比较
表4 2组患者手术相关指标比较及并发症发生率比较
表5 导管异位单因素分析
表6 导管异位并发症的Firth偏倚校正Logistic回归分析结果
表7 不同入路术后不适分级等级比较[例(%)]
表8 两位医师手术相关指标比较
[1]
Niederhuber JE, Ensminger W, Gyves JW, et al. Totally implanted venous and arterial access system to replace external catheters in cancer treatment[J]. Surgery, 1982, 92(4): 706-712.
[2]
中国中西医结合学会外周血管疾病委员会中心静脉通路专家组. 静脉输液港植入与管理多学科专家共识(2023版)[J]. 中国普通外科杂志, 2023, 32(6): 799-814.
[3]
中心静脉通路上海协作组. 完全植入式输液港上海专家共识[J]. 介入放射学杂志, 2015, 24(12): 1029-1033.
[4]
张梦肃, 张杰, 金光鑫, 等. 上臂输液港并发导管相关血栓形成危险因素分析及机器学习预测模型构建[J]. 介入放射学杂志, 2025, 34(3): 253-260.
[5]
Chen YB, Bao HS, Hu TT, et al. Comparison of comfort and complications of implantable venous access port (IVAP) with ultrasound guided internal jugular vein (IJV) and axillary vein/subclavian vein (AxV/SCV) puncture in breast cancer patients: a randomized controlled study[J]. BMC Cancer, 2022, 22(1): 248.
[6]
Carlsson AM. Assessment of chronic pain. I. Aspects of the reliability and validity of the visual analogue scale[J]. Pain, 1983, 16(1): 87-101.
[7]
Boonstra AM, Schiphorst Preuper HR, Reneman MF, et al. Reliability and validity of the visual analogue scale for disability in patients with chronic musculoskeletal pain[J]. Int J Rehabil Res, 2008, 31(2): 165-169.
[8]
Shin HJ, Na HS, Koh WU, et al. Complications in internal jugular vs subclavian ultrasound-guided central venous catheterization: a comparative randomized trial[J]. Intensive Care Medicine, 2019, 45(7): 968-976.
[9]
Mu C, Zhu Z, Miao D, et al. Clinical efficacy and safety of a new single-incision axillary vein puncture technique for totally implantable venous access ports[J]. Sci Rep, 2025, 15(1): 7281.
[10]
Weiner MM, Geldard P, Mittnacht AJ. Ultrasound-guided vascular access: a comprehensive review[J]. J Cardiothorac Vasc Anesth, 2013, 27(2): 345-360.
[11]
O'Grady NP, Alexander M, Burns L A, et al. Guidelines for the prevention of intravascular catheter-related infections[J]. Am J Infect Control, 2011, 39(5): S1-S34.
[12]
中国抗癌协会肿瘤介入学专业委员会. 肿瘤患者完全植入式静脉输液港临床实践与质控指南(2024版)[J]. 四川大学学报(医学版), 2025, 56(2): 400-410.
[13]
Gu J, Wei G, Li L, et al. Catheter allotopia with totally implantable access port: a report of three cases and literature review[J]. Clin Case Rep, 2020, 8(5): 1-5.
[14]
Kartsouni V, Moschouris H, Bersimis F, et al. Complications of totally implantable central venous catheters (ports) inserted via the internal jugular vein under ultrasound and fluoroscopy guidance in adult oncology patients: a single-center experience[J]. Cureus, 2022, 14(7): e27485.
[15]
Ängeby E, Adrian M, Bozovic G, et al. Central venous catheter tip misplacement: a multicentre cohort study of 8556 thoracocervical central venous catheterisations[J]. Acta Anaesthesiologica Scandinavica, 2024, 68(4): 520-529.
[16]
Liu W, Han Q, Li L, et al. Catheter malposition analysis of totally implantable venous access port in breast cancer patients[J]. Front Surg, 2023, 9: 1061826.
[17]
Shinde PD, Jasapara A, Bansode K, et al. A comparative study of safety and efficacy of ultrasound-guided infra-clavicular axillary vein cannulation versus ultrasound-guided internal jugular vein cannulation in adult cardiac surgical patients[J]. Ann Card Anaesth, 2019, 22(2): 177-186.
[18]
Sharp R, Cummings M, Fielder A, et al. The catheter to vein ratio and rates of symptomatic venous thromboembolism in patients with a peripherally inserted central catheter (PICC): a prospective cohort study[J]. Int J Nurs Stud, 2015, 52(4): 677-685.
